Twinlock Netting

Twinlock Netting

Designed for stock security. Line wires are spaced for different stock types to provide strength and security at the most needed points of contact.

Twinlock Knot DrawingAn economical Fabricated Fence option made from High Tensile wire unless otherwise specified. Stay wires run between the horizontal wires and are individually wrapped onto the line wire and tied in with a new stay wire that leads down to the next horizontal. Tension curves are used to create overall rigidity and elasticity. The load of the fence will spread through the hinge and along the line wires.



TYPE USE
Field Fence Sheep and cattle, conservation and forestry blocks
Soft Can be electrified for break feeding lambs / docking
Light Low stock pressure, urban

Line Wire Spacings

Cyclone Product  Cyclone Product
TYPE DESCRIPTION LINE
WIRES
HEIGHT
(mm)
STAY WIDTH
(mm)
ROLL
LENGTH
(m)
FIELD FENCE B5 / 525** 5 525 150 100
  BL7 / 900* 7 900 300 50/100
  B7 / 900 7 900 300 50 / 100
  BL8 / 900* 8 900 150 / 300 50 / 100
  B8 / 900 8 900 150 / 300 50 / 100
  B8 / 800 8 800 300 100
  * Light - uses a 2.00mm HT wire for line wires
  ** Soft - uses LT wire for line wires
